J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN
Description
Detail
630
12
Stop
Engine
Red
3697
Engine Control Module
Calibration Memory
Engine Control Module
Calibration Memory - Bad
intelligent device or component
633 31
Check
Engine
Amber
2311
Engine Fuel Actuator 1
Control Command
Electronic Fuel Injection Control
Valve Circuit - Condition Exists
639 9
Check
Engine
Amber
285
J1939 Network #1,
Primary Vehicle Network
(previously SAE J1939
Data Link)
SAE J1939 Multiplexing PGN
Timeout Error - Abnormal
update rate
639 13
Check
Engine
Amber
286
J1939 Network #1,
Primary Vehicle Network
(previously SAE J1939
Data Link)
SAE J1939 Multiplexing
Configuration Error - Out of
Calibration
640 14
Stop
Engine
Red
599
Engine External Protection
Input
Auxiliary Commanded Dual
Output Shutdown - Special
Instructions
641 7
Check
Engine
Amber
2387
Engine Variable Geometry
Turbocharger Actuator #1
VGT Actuator Driver Circuit
(Motor) - Mechanical system not
responding or out of adjustment
641 9
Check
Engine
Amber
1894
Engine Variable Geometry
Turbocharger Actuator #1
VGT Actuator Driver Circuit -
Abnormal update rate
641 11
Check
Engine
Amber
2198
Engine Variable Geometry
Turbocharger Actuator #1
VGT Actuator Driver Circuit - Root
Cause Not Known
641
12
Stop
Engine
Red
2634
Engine Variable Geometry
Turbocharger Actuator #1
VGT Actuator Controller - Bad
intelligent device or component
641 13
Stop
Engine
Red
2449
Engine Variable Geometry
Turbocharger Actuator #1
VGT Actuator Controller - Out of
Calibration
641
15
Check
Engine
None
1976
Engine Variable Geometry
Turbocharger Actuator #1
VGT Actuator Driver Over
Temperature (Calculated) - Data
valid but above normal
operational range - Least Severe
Level
641 31
Stop
Engine
Red
2635
Engine Variable Geometry
Turbocharger Actuator #1
VGT Actuator Driver Circuit -
Condition exists
647 3
Check
Engine
None 6263
Engine Fan Clutch 1
Output Device Driver
Fan Control Circuit - Voltage
above normal, or shorted to
high source
647 4
Check
Engine
None 6264
Engine Fan Clutch 1
Output Device Driver
Fan Control Circuit - Voltage
below normal, or shorted to
low source
651
5
Check
Engine
Amber
322
Engine Injector
Cylinder #01
Injector Solenoid Driver Cylinder 1
Circuit - Current below normal or
open circuit
652 5
Check
Engine
Amber
331
Engine Injector
Cylinder #02
Injector Solenoid Driver Cylinder 2
Circuit - Current below normal or
open circuit
