J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN
Description
Detail
3226 9
Check
Engine
Amber
2771
Aftertreatment 1
Outlet NOx
Aftertreatment 1 Outlet NOx
Sensor - Abnormal update rate
3226 10
Check
Engine
None 6565
Aftertreatment 1
Outlet NOx
Aftertreatment 1 Outlet NOx
Sensor - Abnormal rate of change
3226 13
Check
Engine
Amber
3717
Aftertreatment 1
Outlet NOx
Aftertreatment 1 Outlet NOx
Sensor - Out of Calibration
3226 20
Check
Engine
None
6462
Aftertreatment 1
Outlet NOx
Aftertreatment 1 Outlet NOx
Sensor - Data not Rational -
Drifted High
3226
21
Check
Engine
None
6463
Aftertreatment 1
Outlet NOx
Aftertreatment 1 Outlet NOx
Sensor - Data not Rational -
Drifted High
3228
2
Check
Engine
None
6582
Aftertreatment 1 Outlet
Gas Sensor Power Status
Aftertreatment 1 Outlet NOx
Sensor Power Supply - Data is
erratic, intermittent, or incorrect
3242 0
Stop
Engine
Red
3311
Aftertreatment 1 Diesel
Particulate Filter Intake
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Intake
Temperature - Data valid but
above normal operation
3242
2
Check
Engine
Amber
3318
Aftertreatment 1 Diesel
Particulate Filter Intake
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Intake
Temperature - Data is erratic,
intermittent, or incorrect
3242 3
Check
Engine
Amber
3317
Aftertreatment 1 Diesel
Particulate Filter Intake
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Intake
Temperature Sensor Circuit -
Voltage above normal, or shorted
to high source
3242 4
Check
Engine
Amber
3316
Aftertreatment 1 Diesel
Particulate Filter Intake
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Intake
Temperature Sensor Circuit -
Voltage below normal, or shorted
to low source
3242 15
Check
Engine
Amber
3254
Aftertreatment 1 Diesel
Particulate Filter Intake
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Intake
Temperature - Data valid but
above normal operating range
3242 16
Stop
Engine
Red
3253
Aftertreatment 1 Diesel
Particulate Filter Intake
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Intake
Temperature - Data valid but
above normal operating range
3246 0
Stop
Engine
Red
3312
Aftertreatment 1 Diesel
Particulate Filter Outlet
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Outlet
Temperature - Data valid but
above normal operation
3246
2
Check
Engine
Amber
3322
Aftertreatment 1 Diesel
Particulate Filter Outlet
Gas Temperature
Aftertreatment 1 Diesel
Particulate Filter Outlet
Temperature - Data is erratic,
intermittent, or incorrect
