MacDon M1240 - Page 585

215916 565 Revision A
J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN
Description
Detail
3597
12
Check
Engine
Amber
351
ECU Power Output Supply
Voltage #1
Injector Power Supply - Bad
intelligent device or component
3597
17
Check
Engine
None 6499
ECU Power Output Supply
Voltage #1
ECU Power Output Supply Voltage
1 - Data valid but below normal
operating range - Moderately
Severe Level
3597 18
Check
Engine
Amber
1938
ECU Power Output Supply
Voltage #1
ECU Power Output Supply Voltage
1 - Data valid but below normal
operating range - Moderately
Severe Level
3610
2
Check
Engine
None 6553
Aftertreatment Diesel
Particulate Filter Outlet
Pressure
Aftertreatment 1 Diesel
Particulate Filter Outlet Pressure -
Data is erratic, intermittent, or
incorrect
3610 3
Check
Engine
None
6551
Aftertreatment Diesel
Particulate Filter Outlet
Pressure
Aftertreatment 1 Diesel
Particulate Filter Outlet Pressure
Sensor Circuit - Voltage above
normal, or shorted to high source
3610 4
Check
Engine
None 6552
Aftertreatment Diesel
Particulate Filter Outlet
Pressure
Aftertreatment 1 Diesel
Particulate Filter Outlet Pressure
Sensor Circuit - Voltage below
normal, or shorted to low source
3667
2
Stop
Engine
Red
5221
Engine Air Shutoff Status
Engine Air Shutoff Status - Data is
erratic, intermittent, or incorrect
3667 3
Check
Engine
Amber
3139
Engine Air Shutoff Status
Engine Air Shutoff Circuit -
Voltage above normal, or shorted
to high source
3667 4
Check
Engine
Amber
3141
Engine Air Shutoff Status
Engine Air Shutoff Circuit -
Voltage below normal, or shorted
to low source
3667 7
Stop
Engine
Red
4484
Engine Air Shutoff
Engine Air Shutoff - Mechanical
System Not Responding or Out of
Adjustment
3695
2
Check
Engine
None 6568
Aftertreatment
Regeneration Inhibit
Switch
Aftertreatment Regeneration
Inhibit Switch - Data is erratic,
intermittent, or incorrect
3703 31
Check
Engine
Amber
(Blinking)
2777
Diesel Particulate Filter
Active Regeneration
Inhibited Due to
Inhibit Switch
Particulate Trap Active
Regeneration Inhibited Due to
Inhibit Switch - Condition Exists
3713 31
Check
Engine
Amber
6596
Diesel Particulate Filter
Active Regeneration
Inhibited Due to
Diesel Particulate Filter Active
Regeneration Inhibited Due to
System Timeout - Condition exists
3750
14
Check
Engine
Amber
5938
Diesel Particulate Filter 1
Conditions Not Met for
Active Regeneration
Diesel Particulate Filter 1
Conditions Not Met for Active
Regeneration – Condition exists
REFERENCE
