NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 98
Revision 3.0
ASYD
SYSTEM
DATA
TYPE (SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
29
b
0
Message Center Interface Output Designation
“1” is to be assigned to each bit corresponding to the Port Num-
ber of the IOC Circuit Card.
b
0
= Port 0 b
4
= Port 4
b
1
= Port 1 b
5
= Port 5
b
2
= Port 2 b
6
= Port 6
b
3
= Port 3 b
7
= Port 7
Note: In the case of dual output ports service, assign “1” to
both ports.
b
1
b
2
b
3
b
4
b
5
b
6
b
7
30
Mounting capacity of Data Memory (DM)
For IMX, assign 02 Hex.
31
Mounting capacity of Common Memory (CM) 1~4 Mbyte
(01~04)
For IMX, assign 02 Hex.
For IMX, assign 04H with OAI name display
32
0
b
0
Not used
1
b
1
Record Tenant Data for SMDR/CS Report
1
b
2
Record Selected Trunk type for SMDR/CS Report
0
b
3
Not used
0
b
4
b
5
When Recording Called Numbers for SMDR:
0/1 = The ACC Code is not to be included/The ACC Code is to
be included.
b
6
When Recording Abbreviated Digit Codes for SMDR:
0/1 = The Digits are Recorded/Digits Dialed are Recorded.
b
7
SMDR/CS Report
0/1 = Out/In Service
