NEC NEAX 7400 IMX - TCP;IP Connection (IP Address over the External LAN)

ND-70348 (E) CHAPTER 2
Page 25
Revision 3.0
HOW TO OPERATE MAT
Figure 2-4 shows the configuration of the PBX and IMX MAT when connecting to an existing LAN. In most cases
you should use a network device such as a HUB or bridge in order to provide isolation from excessive network traf-
fic.
Figure 2-4 TCP/IP Connection (IP Address over the external LAN)
SERVER
PC
LAN
MAT
HUB
MAT PRINTER
10BASE-T straight cable
PC
IMX
LANI
LANI
