ND-70348 (E) CHAPTER 4
Page 623
Revision 3.0
AFPD
AFPD: Assignment of Fusion Tandem PAD Data for LDM
1. General
This command is used to assign PAD data for connection route. This command is available for the software Re-
lease 3 or later.
2. Precautions
1. This data has priority over the data assigned by PAD, ACRD.
2. When a data is input on this command, the data in the ACRD CDN6: PAD must be "7".
3. Data Entry Instructions
TYPE OF CONNECTION
(TYPE)
OUTGOING
CONNECTION ROUTE
(OG_C_RT) 1-1023
INCOMING PAD DATA
(ICPAD)
1-15
OUTGOING PAD DATA
(OGPAD)
1-15
INCOMING ROUTE
(IC_RT)
1-255
TYPE
1 = ICRT→C_RT
IC_RT
Assign the incoming route number
ICPAD
1-14 = Note 15 = PAD OFF (0dB)
OG_C_RT
1
1
1
OGPAD
Assign the outgoing connection route
number Originated to the outside of the
node
When TYPE = 1 is assigned
TYPE OF CONNECTION
(TYPE)
OUTGOING
CONNECTION ROUTE
(OG_C_RT) 1-1023
INCOMING PAD DATA
(ICPAD)
1-15
OUTGOING PAD DATA
(OGPAD)
1-15
INCOMING ROUTE
CONNECTION
(IC_C_RT) 1-1023
TYPE
2 = C_RT→C_RT
IC_C_RT
Assign the incoming route number
OGPAD
OG_C_RT
2
2
2
ICPAD
When TYPE = 2 is assigned
Assign the outgoing connection
route number
1-14 = Note 15 = PAD OFF (0dB)
1-14 = Note 15 = PAD OFF (0dB)
1-14 = Note 15 = PAD OFF (0dB)
Note: PAD value differs depending on the specification of each circuit card. As to the detail setting of PAD
value on each circuit card, refer to the Circuit Card Manual or related system manuals.
To Next Page
