ND-70348 (E) CHAPTER 4
Page 557
Revision 3.0
ATTD
ATTD: Assignment of Trunk Test Data
1. General
This command is used to assign, delete and display trunk connection test data.
2. Precautions
It cannot be executed to overwrite the existing data in this command.
3. Data Entry Instructions
a.) When TYPE=1
Note: Each trunk is automatically tested eight seconds after the previous digits have been sent out. If Test Tone
(TT) or Ring Back Tone (RBT) has been acknowledged, an error is indicated.
INFORMATION
TYPE
(TYPE)
1/2
ROUTE
TYPE
(RT TYPE)
1/2
ROUTE
NUMBER
(RT)
1-255
RESPONSE
PATTERN
(RESP)
1-3
LOGICAL
ROUTE
NUMBER
(LGRT)
1-899
DIAL CODE
(DC)
Max. 24 Digits
LGRT
Enter the Logical Route
Number when RT
TYPE=2 is assigned.
TYPE
TYPE
1 = Trunk Test Parameters
2 = LENS of the LTST circuit card
1 = Route Number
2 = Logical Route Number
RESP
1 = Test Tone (Continuous 1kHz Tone)
2 = Ring Back Tone
3 = Time Over (No Tone) Note
RT TYPE
Enter the Route Number
when RT TYPE=1 is
assigned.
RT
1
To Next Page
