ND-70348 (E) CHAPTER 4
Page 252
Revision 3.0
ASTPL
ASTPL: Assignment of Signal Translation Pattern for LDM
1. General
This command is used to assign the Incoming/Outgoing Selection Translation Pattern Number (PNI/PNO) for
incoming or outgoing trunk route. This data is written in Local Data Memory (LDM).
2. Precautions
1. The PNI/PNO is an intermediate parameter to assign additional number (and skip digits) by the AISPL/
AOSPL command.
(a) When IC/OG=I (Incoming) is entered, the additional number is assigned by the AISPL command.
(b) When IC/OG=O (Outgoing) is entered, the additional number and skip digits are assigned by the
AOSPL command.
2. The transmit number translation of the OGC/OGCA method outgoing calls are done by ASTPL/AOSPL
command. Since the additional number and skip digits can be assigned by the AOPRL /AADCL command
for LCR/LCRS method, the ASTPL/AOSPL command may not be required.
3. The system processes ASTPL/AISPL command prior to the numbering plan data. Thus, if the LCR access
code is added to the received numbers by the ASTPL/AISPL command, the system processes the LCR re-
lated command such as ASPAL/AFRSL /AOPRL.
4. The applicable tenant number (TN) range is designated by the ASYD command, SYS1, INDEX8. Enter
the tenant number in which this command effects. If data of this command is common for all tenants (ASY-
DL command, SYS1, INDEX800, bit4,5=1), assign TN parameter as data “1” for all tenants.
3. Data Entry Instructions
PNI appears when IC/OG=I is entered. Enter any number with
a range from 1 to 15.
I=Incoming
O=Outgoing
PNI
IC/OG
KIND OF
ASSIGNMENT
(IC/OG)
I/O
TENANT
NUMBER
(TN)
1-63
LOGICAL
ROUTE
NUMBER
(LGRT)
1-899
INCOMING SELECTION
TRANSLATION
PATTERN NUMBER
(PNI)
1-15
OUTGOING SELECTION
TRANSLATION
PATTERN NUMBER
(PNO)
1-15
pnip
PNO
I1001 1
PNO appears when IC/OG=O is entered. Enter any number
with a range from 1 to 15.
PNO
