NEC NEAX 7400 IMX - Serial;Dialup Connection to IMX; TCP;IP Connection to Dual CPR of IMX

ND-70348 (E) CHAPTER 2
Page 24
Revision 5.0
HOW TO OPERATE MAT
2.3 Serial/Dialup Connection to IMX
Figure 2-2 Serial/Dialup Connection to IMX
The IMX MAT software provides an advanced communication pathway for IMX. IMX is maintained via the LAN,
WAN, or TCP/IP network on which it is running. Figure 2-3 below shows the simple configuration of the TCP/IP
connection. Using this connection, any node within the Netfusing Link network can be accessed from IMX MAT.
Figure 2-3 TCP/IP Connection to Dual CPR of IMX
Netfusing LINK
IMX
IMX
IMX MAT
IMX MAT PRINTER
IOC
2400 RS - 232C CA - 3
68PH S 2 PORTS CA - A
LC
TRK
MODEM
MODEM
TELECOMUNICATION
NETWORK
Netfusing LINK
10 BASE -T straight cable
HUB
IMX MAT
IMX MAT PRINTER
LANI
LANI
IMX
IMX
