ND-70348 (E) CHAPTER 4
Page 82
Revision 3.0
ASYD
4. Data Sheet
Note: When setting outgoing restriction and toll restriction in the CCIS using the caller’s RSC transferred by a
call origination from the preceding office, data value “1” is assigned. Note, however, that destination re-
striction and number restriction cannot be made by use of RSC. This data is assigned “1” when the Au-
thorization Code is provided.
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
0
Number of MG (Module Group)
IMX = 01~08 (MG00~07)
(For 16-IMG system)
01Hex ~ 20Hex (MG00 ~ MG32)
101 Number of Main Processor (fixed to “01”)
2
b
0
0/1 = Built-in ACDP is not provided/provided
b
1
~b
7
Not used
3
Configuration of Time Division System
01 = Single, 02 = Dual
4
b
0
Control of ORT all Busy Status
0/1 = ROT/Queue
b
1
Recalling method when the caller has released with Emergency
Call service
0/1 = SHF or Depressing Ground Button/Unconditional Recall-
ing
Note: The operating procedure for recall is different de-
pending on the D
term
65 or D
term
75.
D
term
65 user operates with SHF.
D
term
75 user operates with transfer key.
b
2
Releasing Method for Station to Station Calling Service
0 0 = Calling Party release
0 1 = Called Party release
1 0 = First Party release
1 1 = Both Party release
Normally assign “First Party release”
b
3
b
4
Temporary Class Conversion/OAI Free Location Memory
0/1 = Not Required/Required Note
b
5
PAD Control of 16LC circuit card (for Station to Station Call-
ing only)
0/1: Required/Not Required
b
6
One Burst of Ringing On Call Forwarding (C.F.) phone when
C.F. – All Calls service has been assigned (analog phones
only).
0/1 = Not Required/Required
b
7
Emergency Call Printout – 0/1 = No Printout/Printout
