ND-70348 (E) CHAPTER 4
Page 466
Revision 3.0
ATGL
ATGL: Assignment of Trunk Group Busy Lamp Data
1. General
This command is used to assign the data related to the Trunk Group Busy Lamp which is accommodated on the
Attendant Console.
2. Precautions
1. The maximum number of Attendant Consoles should be assigned by the ASYD command, SYS 1, INDEX
9.
2. The Trunk Group Busy Lamp is lit when the trunk routes specified by the RT parameter of this command
are engaged.
3. The number of Trunk Group Busy Lamps to be applied (capable TGN data range) is designated by the
ASYD command, SYS1, INDEX15, bit0-3.
3. Data Entry Instructions
Attendant Console number assigned by
the ATRK command
ATN
REMARKROUTE
NUMBER
(RT)
TRUNK
GROUP
(TGN)
1-10
ATTENDANT
NUMBER
(ATN)
Enter the route number composed the TGN
RT
To Next Page
