ND-70348 (E) CHAPTER 4
Page 574
Revision 3.0
ACSA
ACSA: Assignment of Connection Service Index A
1. General
This command is used to assign the call termination for CAS Line and Direct-in Termination (Day Only).
2. Precautions
1. The ACFR command assignment is also required to accomplish the trunk incoming call termination service
feature.
2. CAS data at the Satellite Station
(a) It is necessary to set the TEC (Telephone Class) of the CAS Line to “15” in the ASDT command.
(b) A ring-down incoming call from a C.O line is terminated to the CAS Line.
3. When assigning CSIA=3 (Direct-in Termination-outside (Day Only)), the ADC should be assigned by the
ASPD command.
4. Use the ACSI command instead of this command if Direct-in Termination (Day and Night Mode) or Di-
rect-in Termination (Night Mode) is required.
5. The applicable tenant number (TN) range is designated by the ASYD command, SYS 1, INDEX 8.
3. Data Entry Instructions
ROUTE
NUMBER
(RT)
CONNECTION
SERVICE
INDEX A
(CSIA)
1-7
TRUNK
NUMBER
(TK)
TENANT
NUMBER
(TN)
STATION NUMBER
(STN)
ABBREVIATED
DIGIT CODE (ADC)
MAX. 4 DIGITS
TERMINATING STATION
CSIA
1 = CAS Line
2 = Direct-In Termination(Day only)
3 = Direct-In Termination-Outside (Day only)
4-7 = Not used
1 0 0 1 1 or 2 0 1 0 3 1 1 1
20013 0011
ADC
This parameter is required only for
CSIA=3.
To Next Page
