NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 415
Revision 3.0
ARTDN
Figure 4-16 SMDR2 (ARTDN)
b
0
b
1
b
2
b
3
0/1: -/Incoming Call (SMDR is required)
0/1: SMDR is required for toll and local out-
going calls/SMDR is required only for toll
outgoing calls.
0:
1:
2:
3:
Metering pulses are necessary. Hexadecimal
assignment is “01.”
Example:
b
0
b
1
b
2
b
3
000
1
8421
b
0
=bit 0
b
1
=bit 1...
The following explains what hexadecimal data “1” means for SMDR2:
• For incoming calls SMDR is required because Bit 0 is assigned as one (1).
• SMDR is required for toll and local outgoing calls because Bit 1 is assigned as zero (0).
• Metering pulses are detected by the system; therefore Bit 2 is zero (0) and Bit 3 is zero (0).
