ND-70348 (E) CHAPTER 4
Page 414
Revision 3.0
ARTDN
LGRT
1-899
FUNCTION
REMARKS
13
AC Flexible Routing Pattern Designation
When outgoing route selection pattern number is to be determined
by the AFRS command, “1” is to be assigned if the Access Code is
included in the Number Pattern Code (NPC).
0= When flexible routing is executed, numbers are translated exclud-
ing the Access Code.
1= When flexible routing is executed, numbers are translated includ-
ing the Access Code.
This data is valid for dummy
routes.
Assign data "1" for the dummy
route.
14
TNT Tenant Number Check
0 = Tenant number check is not required in trunk selection.
This data should always be as-
signed as “0”
15
LSG Line Signal
0= Loop
1= Ground Start C. O. Line
2= CDH
3= Caller ID (Loop)
4= Loop
5= E&M Tie Line
6= DX
7= 24V4
8= Loop DID 9-11= Not used
12= Speech Line ( for CCIS No.7 or Bch of ISDN)
13= Signal Line ( for CCIS No.7 or Dch of ISDN)
14= Not used 15= Not used
16
SMDR2 Detailed Billing Information See Figure 4-16 (Next Page)
and Table 4-22
(page 416)
.
17
H/M Hotel Service in CCIS No.7
0= Out of Service 1= In Service
18MC 0000Always assign data “0”.
19
ANI E911-ANI Service
0= Out of Service 1= In Service
20D 0000Always assign data “0”.
21MSB 0000Always assign data “0”.
22MSW 0000Always assign data “0”.
23
TR 0= -
1= ICPT transfer by group-II signals used.
For MFC signaling.
To Next Page
