AEKD: Assignment of External Key Data
1. General
This command is used to assign the External Key related data, which allows a maintenance person to change
the system over to the Day/Night mode by means of ON/OFF on the PFT circuit card.
2. Precautions
1. When the “PFT control by the external key” is required, the following data assignments are needed:
(a) AUNT command, TYPE=2 (PFT)
(b) AEKD command
(c) ANCD command
(d) ACSI command, CSI=4 (Direct-in Termination (Night Mode))
2. A maximum of eight (0-7) external keys can be assigned, corresponding to each PFT circuit card. The ex-
ternal key can control two PFT circuit cards per MG (16 circuits).
3. Data Entry Instructions
1 = -
2 = Day/Night Change
3 = -
4 = -
CP
One external key can manage
8 tenants at the maximum
TN
MODULE
GROUP
(MG)
0-7
CIRCUIT
CARD NO.
(NCU PKG)
0/1
EXTERNAL
KEY
NUMBER
(CTN)
0-7
CHANGE
CONTROL
PATTERN
(CP)
1-4
NUMBER OF INPUT TN OR RT/TK (CNT)
TN
1st 2nd 3rd 4th 5th 6th 7th 8th
0
1
2
3
4
5
6
To Next Page
