ND-70348 (E) CHAPTER 4
Page 338
Revision 3.0
AKYD
6. If the station user accepts the default settings, the data assignment of this command is not required. The
default data for each line/feature button is shown below.
7. The ability to assign Sub Line appearances across module groups is available when ASYD command
SYS1, INDEX321, bit0 = 1 is assigned. Stations can appear on D
term
which accommodated the different
module group within the same IMG.
8. When assigning the line/feature buttons as function keys, take the following precautions:
(a) My Line key must be programmed.
(b) Not used line/feature buttons should be assigned as KYI = 0 (Not used)
(c) The following function keys are basically fixed:
FKY = 13:CONF (Three - Way Calling)
FKY = 18:TRANSFER (Call Transfer-All Calls)
FKY = 20:HOLD (Non - Exclusive Hold/ Exclusive Hold)
FKY = 28:ANSWER
FKY = 51:MIC
FKY = 52:SPEAKER
FKY = 57:RECALL
9. The applicable tenant number (TN) range is designated by the ASYD command, SYS1, INDEX8.
Table 4-11 Default Data for Each Line/Feature Button
KEY NO. DEFAULT DATA KEY NO. DEFAULT DATA
1 CALL PICKUP 9 PRIME LINE
2 CALL FORWARDING - BUSY LINE 10 SPEED CALLING ONE-TOUCH
3
CALL FORWARDING - ALL CALLS
CALL FORWARDING - DON’T ANSWER
11
SPEED CALLING ONE-TOUCH
4 EXECUTIVE RIGHT OF WAY 12 SPEED CALLING ONE-TOUCH
5 VOICE CALL 13 SPEED CALLING ONE-TOUCH
6 MESSAGE REMINDER 14 SPEED CALLING ONE-TOUCH
7 SAVE AND REPEAT 15 SPEED CALLING ONE-TOUCH
8 LAST NUMBER CALL 16 SPEED CALLING - SYSTEM
