ND-70348 (E) CHAPTER 4
Page 476
Revision 3.0
APADN
APADN: Assignment of PAD Data for NDM
1. General
This command is used to assign PAD control data for tandem connections, and trunk to station connections in
Netfusing system. The data assigned by this command is written in the Network Data Memory (NDM) of the
Network Control Node (NCN), updating the NDM at each Local Node (LN).
2. Precautions
When KIND = S (Station) is designated, assign the dummy data to the parameter “OGPAD”.
3. Data Entry Instructions
The kinds of connection entering
in this parameter are as follows.
T=Tandem Connection
S=Station
KIND
This parameter is not required when
KIND=T (Tandem Connection) is
assigned.
SFC
0=No APADN Setting
1-14=Note 15=PAD OFF (0dB)
ICPAD/OGPAD
Enter the Logical Route Number of Incoming
Route. When KIND=S (Station) is assigned,
this parameter is not required.
Enter the Logical Route Number
of Outgoing Route.
ICLGRT
KIND OF
CONNECTION
(KIND)
T/S
INCOMING
LOGICAL
ROUTE
NUMBER
(ICLGRT)
1-899
OUTGOING
LOGICAL
ROUTE
NUMBER
(OGLGRT)
1-899
SERVICE
FEATURE
CLASS
(SFC)
0-15
INCOMING
PAD DATA
(ICPAD)
1-15
OUTGOING
PAD DATA
(OGPAD)
1-15
OGLGRT
Note: Switch setting varies depends on the
trunk circuit card. Refer to “Circuit
Card Manual”.
