ND-70348 (E) CHAPTER 4
Page 305
Revision 3.0
AARPL
AARPL: Assignment of Area Code Restriction Data for LDM
1. General
This command is used to assign the area/office code of Toll Restriction - 3/6 digits for Netfusing service con-
junction with ATDPL (for LDM)/ATDPN (for NDM) command. This data is written in Local Data Memory
(LDM). When common data is needed in the Netfusing Network, assign the data by the AARPN command.
2. Precautions
1. This command is used when restriction data is assigned to RES=2 (Toll Restriction is required) in the AR-
SCL (LDM)/ARSCN (NDM) command or in the ARRCN command.
2. This command is available since Release 7.5 software enhancement.
3. Data Entry Instructions
Note: In case the data has already been assigned when “Get” button is executed after checking “6 Digits” pa-
rameter and entering DC=000000, “Del” button is not valid while “Set” button is to be effective. Then the
restriction data can be changed (overwritten) by “Set” button.
OUTGOING
LOGICAL
ROUTE
NUMBER
(OG-LGRT)
1-899
ROUTE
RESTRICTION
CLASS(RSC)
0-15
FLAG OF 3 OR
6 DIGITS
(FLAG)
3 Digits/6 Digits
DESTINATION
(AREA/OFFICE)
CODE (DC)
MAX .6 DIGITS
RESTRICTION
DATA (RES) 0/1
REMARKS
FLAG
Select either "3 Digits" or
"6 Digits" check box.
RES
0 = Area/Office code is restricted.
1 = Area/Office code is allowed.
OG-LGRT
Assign a unique LGRT No.
in the Netfusing Network.
DC should not include the access code.
DC
RSC assigned by the ARSCN command.
RSC
To Next Page
