ND-70348 (E) CHAPTER 4
Page 645
Revision 5.0
AIPDL
AIPDL: Assignment of IP Service PAD Data for LDM
1. General
This command is used to assign and delete the PAD data for IP service. It can also be used for reading out the
already assigned data to modify it. This data is written in the Local Data Memory (LDM).
2. Precautions
1. This command is valid when IPTRK service software is programmed.
2. PAD data of IP Trunk card can be assigned per Node as the pattern shown in the table below;
X: PAD data can be flexibly assigned by this command.
3. If both “NODE” and “IPG” data for IC/OG Terminal parameter are restricted, this command cannot be
used.
4. This command is available for the software Release 9 or later.
5. “IPG” parameter is available since Release 10 software enhancement.
IC TERMINAL OG TERMINAL IC PAD OG PAD DATA
Trunk
IPTRK
X X RT-Node
Analog Telephone/Dterm PAD OFF X Node-SFC
ISDN Terminal PAD OFF X Node-SFC
Connection Trunk X X C_RT-Node
IPELC
X X IPG-Node
IPELC X X IPG-IPG
Trunk X X IPG-RT
Analog Telephone/Dterm X PAD OFF IPG-SFC
ISDN Terminal X PAD OFF IPG-SFC
Connection Trunk X X IPG-C_RT
IPTRK
IPTRK X X Node-Node
IPELC X X Node-IPG
Trunk X X Node-RT
Analog Telephone/Dterm X PAD OFF Node-SFC
ISDN Terminal X PAD OFF Node-SFC
Connection Trunk X X Node-C_RT
