ND-70348 (E) CHAPTER 4
Page 261
Revision 3.0
AFRSL
AFRSL: Assignment of Flexible Route Selection Data for LDM
1. General
This command is used to assign the area and/or office code data for the OPR assigned by the AOPRL command.
This data is written in Local Data Memory (LDM).
2. Precautions
1. The applicable tenant number (TN) range is designated by the ASYD command, SYS1, INDEX8. If data
of this command is common for all tenants (ASYDL command, SYS1, INDEX800, bit4=1), assign TN pa-
rameter as data “1” for all tenants.
2. After an Outgoing Route Selection Pattern Number (OPR) has been assigned in this command, it is neces-
sary to assign the LCR routing pattern/six (6) digits routing pattern by the AOPRL/ASDC command re-
spectively.
3. It should be noted that the access code may or may not be included in the Number Pattern Code (NPC)
depending upon the assignment of AC parameter by the ARTD command. If zero (0) is assigned, the access
code is not included. If one (1) is assigned, the access code must be included.
4. Assign the dummy route number in the LGRT parameter.
5. When assigning such a number as shown below to parameter “NPC”, enter “T” code to the end digit of
“NPC.”
Example:
When assigning 90 and 900 to NPC:
Number
Input Number for NPC OPR
90 90T X
900 900 Y
To Next Page
