ND-70348 (E) CHAPTER 4
Page 310
Revision 3.0
ASFC
ASFC: Assignment of Service Feature Restriction Class
1. General
This command is used to assign the Service Feature Restriction Class (SFC) for the Service Feature Index (SFI).
2. Precautions
1. The service feature name corresponding to the SFI is listed in Table 4-8 on the next page. Since the service
feature indicated “-” in the table may not always “Not used” index, do not enter RES=1 for “-” indicated SFI
due to prevent from unexpected service feature effects.
2. Data can be entered on a Day/Night basis, if specified in ASYD command, SYS1, INDEX75, Bit 1=1.
3. The applicable tenant number (TN) range is designated by the ASYD command, SYS1, INDEX8. If data
of this command is common for all tenants (ASYD command, SYS1, INDEX93, bit0=1), assign TN pa-
rameter as data “1” for all tenants.
4. The displayed SFC (Service Feature Class) corresponds to the one assigned by the ASDT command.
5. The restriction data (RES) is entered in the text box where RSC and RRI cross.
3. Data Entry Instructions
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
RESTRICTION DATA(RES) is assigned in the squares where SFI and SFC
cross. When unassigned, Restriction Data corresponding SFI recognized 0
(Restriction status).
0=Restricted 1=Allowed
SFI
Enter the SFI referring to Table 4-8 (Next Page)
D/N
D = Day mode
N = Night mode
TENANT
NUMBER
(TN)
DAY/NIGHT
MODE
(D/N)
D/N
SERVICE
FEATURE
INDEX
(SFI)
1-255
SERVICE RESTRICTION CLASS (SFC)
To Next Page
