ND-70348 (E) CHAPTER 4
Page 597
Revision 3.0
AARSN
AARSN: Assignment of Alternative Route Service Restriction for NDM
1. General
This command is used to assign various service connections between the outgoing route and the incoming route
when they are to be restricted, or to assign the existing restrictions when such service connections are to be can-
celed. The data assigned by this command is written in the Network Data Memory (NDM) of the Network Con-
trol Node (NCN), updating the NDM at each Local Node (LN).
2. Precautions
1. This command can be used only when logging in to NCN.
2. If the data is not assigned, the specified connections are to be restricted.
3. Data Entry Instructions
INCOMING
LOGICAL
ROUTE
NUMBER
(IC_LGRT)
1-899
OUTGOING
LOGICAL
ROUTE
NUMBER
(OG_LGRT)
1-899
ROUTE
SERVICE
(RSV)
0/1
RESTRICTION
DATA
(RES)
0-2
RES
When RSV = 1 (AMP Pool)
0 = Restriction
1 = OGT
2 = ICT
RSV
0 = Not used
1 = AMP Pool
REMARKS
To Next Page
