NEC NEAX 7400 IMX - ATCR: Assignment of Telephone Class Restriction

ND-70348 (E) CHAPTER 4
Page 783
Revision 3.0
ATCR
ATCR: Assignment of Telephone Class Restriction
1. General
This command is used to assign and display the restriction data for connections between Telephone Equipment
Classes (TECs).
2. Precautions
1. This command is used for the Hotel Application only.
2. Connection between TECs will be allowed for each RSC until they are restricted by this command.
3. TEC 31 is used for ATT in this command.
3. Data Entry Instructions
CALLING TEC
Calling Telephone Equipment Class
1 : DP (10pps) 2 : PB
3 : DP/PB 4 : DP (20pps)
5 : DP (10pps) : Guest 6 : PS : Guest
7 : DP/PB : Guest 8 : DP (20pps) : Guest
9 : House Phone 10 : House Phone : Guest
11 : Not Used 12 : D
term
13 : Data Terminal via D
term
14 : Hot Line
15 : CAS Line 16 : Data Terminal via Data Module
17 : Not Used 18 : Virtual Line Appearance(for D
term
Multi-Line)
19-22 : Not Used 23 : ISDN Terminal
24-25 : Not Used 26 : Not Used
27 : Eight Conference Equipment
28-30 : Not Used 31 : ATT
CALLED TEC
Called Telephone Equipment Class
1 : DP (10pps) 2 : PB
3 : DP/PB 4 : DP (20pps)
5 : DP (10pps) : Guest
6 : PS : Guest
7 : DP/PB : Guest
8 : DP (20pps) : Guest
9 : House Phone 10 : House Phone : Guest
11 : Not Used 12 : D
term
13 : Data Terminal via D
term
14 : Hot Line
15 : CAS Line 16 : Data Terminal via Data Module
17 : Not Used 18 : Virtual Line Appearance(for D
term
Multi-Line)
19-22 : Not Used
23 : ISDN Terminal
24-25 : Not Used
26 : Not Used
27 : Eight Conference Equipment
28-30 : Not Used 31 : ATT
CALLING
TELEPHONE
EQUIP. CLASS
(CALLING TEC)
1-31
CALLED
TELEPHONE
EQUIP. CLASS
(CALLED TEC)
1-31
DAY/NIGHT
MODE
(D/N)
D/N
RESTRICTION
(RES)
0/1
RES
0 : Restricted
1 : Connection is allowed
D/N
D : Day Mode
N : Night Mode
