ND-70348 (E) CHAPTER 4
Page 646
Revision 5.0
AIPDL
3. Data Entry Instructions
INCOMING TERMINAL
(IC TERMINAL)
[RT/SFC/C_RT/NODE/IPG]
OUTGOING TERMINAL
(OG TERMINAL)
[RT/SFC/C_RT/NODE/IPG]
INCOMING PAD
(IC PAD)
[1-15]
OUTGOING PAD
(OG PAD)
[1-15]
REMARKS
Assign the PAD value within the range of 0dB-16dB (1-15).
PAD value for “SFC (station)” is fixed to “1 (PAD OFF)”.
See Note 4 for “IPG” setting.
IC/OG PAD
Check the required parameter according to each terminal. Note 1
RT: External Route Number for the trunk [1-255]
SFC: Service Feature Class for the station [0-15]
C_RT: Connection Route Number [1-1023]
NODE: Enter the Node Number on which IPTRK card is accommodated
(Node Number is assigned by the ANTI command). [Max. 3 digits
(0-9, *, #, P)] Note 2
IPG: IPELC Group Data [0-127] Note 3
IC TERMINAL/OG TERMINAL
To Next Page
