NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 83
Revision 3.0
ASYD
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00-FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
15
b
0
Access Code for C.F.-Busy Line and C.F. – Don’t Answer Ser-
vices
0/1 = Same/Separate
Note: If “0” is assigned, assign either SID: 10 or 12 in com-
mand “ASPA”.
b
1
Maximum number of Multiple Call Forwarding – All Calls/Busy
Line occurrences:
Note: This data is valid when SYS-1, INDEX 69, bit 7 is as-
signed as “1”.
b
2
b
3
b
4
Miscellaneous Timer Counter
(MTC)
(0-7)
Call Back – Delay Timer
Timer Value Setting is MTC ×
2 sec.
When this data is “000”, Timer
value is 2 sec.
b
5
b
6
b
7
Call Back – Delay Timer
0/1 = Ineffective/Effective
b
3
b
2
b
1
b
3
b
2
b
1
000: 100:
001: 101:
010: 110:
011: 111:
once
three times
twice
five times
four time
s
