NEC NEAX 7400 IMX - Page 86

ND-70348 (E) CHAPTER 4
Page 84
Revision 5.0
ASYD
SYSTEM
DATA
TYPE (SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
16
b
0
Special Transmitting Tone When Using Sender (Station) 0/1 =
Not Required/Required (used with LCR/Speed Calling, etc.)
0
b
1
Not used
b
2
Special Transmitting Tone When Using Sender (ATT)
0/1 = Not Required/Required (used with LCR/Speed Calling,
etc.)
b
3
Tone for O/G Connection
0/1 = NEC Standard/Australian (2nd DT on LCR)
b
4
Key pattern on the right side of Attendant Console
Note: Do not set other pattern data.
b
5
b
6
0
b
7
Not used
b
6
b
5
b
4
0 0 0 = pattern 1
0 0 1 = pattern 2
0 1 0 = pattern 3
1 0 0 = pattern 4 (MCT service is invalid.)
