NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 624
Revision 3.0
AFPD
TYPE OF CONNECTION
(TYPE)
OUTGOING
CONNECTION ROUTE
(OG_RT) 1-255
INCOMING PAD DATA
(ICPAD)
1-15
OUTGOING PAD DATA
(OGPAD)
1-15
INCOMING ROUTE
CONNECTION
(IC_C_RT) 1-1023
TYPE
3 = C_RT→RT
IC_C_RT
TYPE
TYPE
Assign the incoming connection
route number
Assign Service Feature Class for the
station.
OGPAD
OG_RT
3
3
3
ICPAD
Assign the outgoing route number
C_RT
Assign the connection route number
When TYPE = 3 is assigned
TYPE OF CONNECTION
(TYPE)
CONNECTION
ROUTE
(C_RT)
1-1023
INCOMING PAD DATA
(ICPAD)
1-15
OUTGOING PAD DATA
(OGPAD)
1-15
SERVICE FEATURE
RESTRICTION CLASS
(SFC)
0-15
TYPE
4 = STN←→C_RT
OGPAD
4
4
ICPAD
When TYPE = 4 is assigned
SFC
1-14 = Note 15 = PAD OFF (0 dB)
1-14 = Note 15 = PAD OFF (0 dB)
1-14 = Note 15 = PAD OFF (0 dB)
1-14 = Note 15 = PAD OFF (0 dB)
Note: PAD value differs depending on the specification of each circuit card. As to the detail setting of PAD
value on each circuit card, refer to the Circuit Card Manual or related system manuals.
