NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 164
Revision 3.0
ASYD
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
204
b
0
LP24 #0 is mounted on PBI60 Module for 16-IMG system
b
1
LP24 #1 is mounted on PBI60 Module for 16-IMG system
0
b
2
Not used
0
b
3
b
4
LP26 #0 is mounted on PBI64 Module for 16-IMG system
b
5
LP26 #1 is mounted on PBI64 Module for 16-IMG system
0
b
6
Not used
0
b
7
205
b
0
LP28 #0 is mounted on PBI68 Module for 16-IMG system
b
1
LP28 #1 is mounted on PBI68 Module for 16-IMG system
0
b
2
Not used
0
b
3
b
4
LP30 #0 is mounted on PBI6C Module for 16-IMG system
b
5
LP30 #1 is mounted on PBI6C Module for 16-IMG system
0
b
6
Not used
0
b
7
206 00 Not used
207
b
0
IP00 System #0
0/1 = Not mounted/Mounted
b
1
IP00 System #1
0/1 = Not mounted/Mounted
b
2
IP01 System #0
0/1 = Not mounted/Mounted
b
3
IP01 System #1
0/1 = Not mounted/Mounted
b
4
IP02 System #0
0/1 = Not mounted/Mounted
b
5
IP02 System #1
0/1 = Not mounted/Mounted
0
b
6
Not used
0
b
7
Not used
208 00 Not used
