NEC NEAX 7400 IMX - Page 211

ND-70348 (E) CHAPTER 4
Page 208
Revision 3.0
ASYDL
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
512-1535
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
640
b
0
FPC (Fusion Point Code) of the node providing ATT-CON.
Assign FPC of a terminating node for operator calls from other
nodes and Ring Down (IC) calls from PSTN.
FPC: 1-253 (01 Hex-FD Hex)
Note: This data is necessary at all nodes. Assign the self
FPC at the terminating node.
b
1
b
2
b
3
b
4
b
5
b
6
b
7
641
b
0
Designation of output numbers for SMDR ICS format.
0/1=Physical (station) number/Telephone number
Note 1: This data is valid when the text format of SMDR is
“ICS format.”
Note 2: Data “1 (Telephone number is output)” is valid
when the number of digits for Telephone number is 6
or less.
Note 3: Valid for the software release 2 or later.
b
1
Designation of output numbers for MCI ICS format.
0/1=Physical (station) number/Telephone number
Note 1: This data is valid when the text format of MCI is
“ICS format.”
Note 2: Data “1 (Telephone number is output)” is valid
when the number of digits for Telephone number is 6
or less.
Note 3: Valid for the software release 2 or later.
0
b
2
Not used
b
3
Designation of output routes for SMDR ICS format.
0/1 = Physical route/Logical route
Note 1: This data is valid when the text format of SMDR is
“ICS format”.
Note 2: Valid for the software release 3 or later.
0
b
4
~b
7
Not used
