NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 220
Revision 3.0
AIOC
3. DATA ENTRY INSTRUCTIONS
IOC port number (#0 or #1 card is specified by IOC switch settings,
#0 IOC card have port number 0 through 3, #1 is 4 through 7)
IOC PORT
NUMBER
(IOC)
0-7
TERMINAL KIND
(TERMINAL)
0-10
IOC
TERMINAL
(SPEED)
0-6
(PARITY BIT)
0-3
(STOP BIT)
0-3
(CHARACTER BIT)
0/1
SPEED
PARITY BIT
STOP BIT
CHARACTER BIT
SYSTEM MESSAGE
SCAN SERVICE
(SYMSCAN)
0/1
TYPE OF MAT
INTERFACE
(MTYPE)
0
(SPEED)
0-6
SYMSCAN
SPEED
MTYPE
0=Not used
2=MAT
4=SMDR(Free wheeling)
5=SMDR(BSC)
0=Default(4800bps)
1=300bps
3=1200bps
5=4800bps
0=Non Parity
1=Odd Parity
2=Even Parity
3=Non Parity
0=2bits
1=1bit
0=8bits
1=7bits
0=Out of service
1=In service
0=Windows base MAT
2=1+1/2bits
3=2bits
2=600bps
4=2400bps
6=9600bps
0=Default(4800bps)
1=300bps
3=1200bps
5=4800bps
2=600bps
4=2400bps
6=9600bps
1=Printer/MCI
3=CMAT
7=PMS
9=ATT0
Note: 7~10 is available for Hotel System.
8=H/M Printer
10=ATT1
6=ATM module
TERMINAL=1 (Printer/MCI)
TERMINAL=2 (MAT)/3 (CMAT)
0
0
