ND-70348 (E) CHAPTER 4
Page 222
Revision 3.0
AIOC
CHARACTER BIT
0=8bits
1=7bits
BUSY SIGNAL
0=(+)
1=(-)
SYNC CHARACTER
0=Bi-sync
1=Mono-sync
PB SIGNAL
0=No PB signal
1=PB signal is required
ENH
(Extended block parameter)
0=Invalid Note
1=Valid (Continue to following attribution data assignment.)
Note: Standard data is "0".
SYNC
0=ST1
1=ST2
(SPEED)
0-6
(PROTOCOL)
0-2
(PARITY BIT)
0-3
(STOP BIT)
0-3
(SYNC)
0/1
(CHARACTER
BIT) 0/1
(SYNC CHAR-
ACTER) 0/1
(BUSY SIGNAL)
0/1
SPEED
0=Default(4800bps)
1=300bps
3=1200bps
5=4800bps
2=600bps
4=2400bps
6=9600bps
PARITY BIT
0=Non Parity
1=Odd Parity
2=Even Parity
3=Non Parity
STOP BIT
0=2bits
1=1bit
2=1+1/2bits
3=2bits
TERMINAL=7 (PMS) / 8 (Hotel Printer)
PROTOCOL
0=Free Wheeling
1=BSC Pooling
2=BSC Contention
3=Level 2A
4=Level 2B
(ENH)
0/1
(PB SIGNAL)
0/1
WR
(Transmission method)
0 Fixed. (RS ON always)
ET
(EOT on reset)
0=Invalid
1=Valid
(PM)
0/1
(CLASS)
0-3
(CN)
0-3
(FL)
0/1
(ET)
0/1
(KJ)
0/1
(WR) (DR)
0/1
PM
(Priority Point specification)
0=First Priority Point
1=Second Priority Point
CN
(Continuous
Transmission)
0=Invalid
1=Valid
FL
(Reception
buffer shortage)
0=NAK
1=WABT
KJ
(Kanji Character code)
0=Invalid
1=Valid
DR
(DR signal disregard)
0=Invalid
1=Valid
Following optional parameters appear when ENH (Extended block parameter) = 1.
CLASS
0=-CR/LF
1=-CR
2=STX-ETX
3=STX-ETX/BCC
To Next Page
