ND-70348 (E) CHAPTER 4
Page 295
Revision 3.0
ARSCN
3. Data Entry Instructions
111
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
RRI-0
RRI-1
RRI-2
RRI-3
0 = IC Restriction via ATT/STA
1 = IC Restriction Directly
2 = OG Restriction via ATT/STA
3 = OG Restriction Directly
See Precautions (4), for more details
RESTRICTION DATA (RES) is assigned in the
squares where RRI and RT cross. When unassigned,
RES for the corresponding item is recognized as “0”
(Restriction Status).
0 = Restricted
1 = Connection is allowed
2 = Toll (Conditional) Restriction
Note:
RES=2 can be set only when PRI-3.
TN
PRI
Enter the tenant number which affects this restriction table
LGRT
Enter the unique Logical Route number in the
Netfusing network.
D/N
D=Day mode
N=Night mode
DAY/NIGHT
MODE
(D/N)
D/N
TENANT
NUMBER
(TN)
LOGICAL
ROUTE
NUMBER
(LGRT)
1-899
ROUTE
RESTRICTION
INDEX
ROUTE RESTRICTION CLASS
(Previous Page)
To Next Page
