ND-70348 (E) CHAPTER 4
Page 321
Revision 3.0
ASDT
3. Data Entry Instructions
1 3 0 0 0 0 0 0 1 2 0 12 1 1
Enter the station number with regard to the followings;
The number of station number (STN) digits is
designated by the ASYD command, SYS 1, INDEX 16.
STN
Enter the RSC defined by the ARSC command. Since RSC = 0 is preserved
for ATTCON, a station can be used the RSC with a range from 1 to 15.
RSC
Enter the SFC defined by the ASFC command. Since SFC = 0 is preserved
for ATTCON, a station can be used the SFC with a range from 1 to 15.
SFC
STATION
NUMBER
(STN)
LINE EQUIPMENT
NUMBER
(LENS)
TELTPHONE
EQUIPMENT
CLASS
(TEC)
1-31
ROUTE
RESTRICTION
CLASS
(RSC)
0-15
SERVICE
FEATURE
CLASS
(SFC)
0-15
REMARKS
TENANT
NUMBER
(TN)
LENS
Enter the LENS of the circuit card
with referring to Figure 4-2.
(Previous Page)
TN
The applicable TN is designated by the ASYD
command, SYS1, INDEX 8.
MG U G LV
TEC
1 = DP(10 pps) 2 = PB
3 = DP/PB 4 = DP (20 pps)
5-11 = Not Used 12 = D
term
13 = Data Terminal via D
term
14 = Hot Line 15 = CAS Line
16 = Data Terminal via Data Module
17 = Not Used
18 = Virtual Line Appearance(for D
term
Multi-Line)
19-22 = Not Used 23 = ISDN Terminal
24-25 = Not Used 26 = Not Used
27 = Eight Conference Equipment
28-31 = Not Used
