NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 336
Revision 3.0
ALGSL
3. Data Entry Instructions
TELEPHONE NUMBER
(TELN) MAX. 16 DIGITS
LINE EQUIPMENT NUMBER
(LENS)
USER GROUP
NUMBER
(UGN)
UGN
TYPE
1 = User Group Number 1 (Fixed)
LENS
LENS of the physical station
TYPE
1 = LENS is used to specify the Telephone number
2 = STN is used to specify the Telephone number
1
1
1
1
1
1
♦ TYPE = 1 (LENS is used to specify the Telephone number.)
TELEPHONE NUMBER
(TELN) MAX. 16 DIGITS
STATION
NUMBER
(STN)
TENANT
NUMBER
(TN)
USER GROUP
NUMBER
(UGN)
UGN
TYPE
1 = User Group Number 1 (Fixed)
STN
Station number of the
physical station
TYPE
1 = LENS is used to specify the Telephone number
2 = STN is used to specify the Telephone number
1
1
2
2
TN
♦ TYPE = 2 (STN is used to specify the Telephone number.)
Tenant number of the physical station
