ND-70348 (E) CHAPTER 2
Page 34
Revision 3.0
HOW TO OPERATE MAT
12. Leave the IP Port text box blank.
13. Leave the Inter-App Resource text box blank.
14. Click Add to write the data.
15. Click Close.
Note: Since Release 7.5 software enhancement, the PBX Administration dialog box changes adapting to multiple
FCCS networks connected via CCIS link.
Enter the Fusion Group (FUG) Number which the PBX to be logged-in belongs. “Connection Timeout”,
“Response Timeout”, and “Pacing Timer” text box is not provided. Others are the same as previous one.
The PBX dialog box is as shown below.
Note: When assigning the PBX Administration data of the Netfusing node (whose FPC is designated within Net-
fusing Network), be sure not to assign “FPC= 0” in normal occasion. Also don’t enter “FUG= 0” when
assigning the PBX Administration information of the node whose FUG is designated within multiple FCCS
networks connected via CCIS link. Though it is possible to log in to a node by inputting “FPC= 0” or
“FUG= 0”, the data is used just for evading measures in case the FPC/FUG number is unknown.
PBX Administration
Add
Add
Modify
Modify
Clear
Close
PBX Alias
Connection Type
FUG
COM Port
Baud Rate
Modem Name
Phone Number
Host Name
IP Address TCP Port
TCP/IP Settings
Serial Settings
TCP/IP
bsc7200
10.41.207.207 60000
3
FPC
1
Delete
TCP-IP134
To Next Page
