ND-70348 (E) CHAPTER 4
Page 382
Revision 3.0
ADA1_T
4. Data Sheet
Note: The existing data can be readout by pressing “Get” button after UGN and TELN is entered.
CDN
User Group Number (UGN)
Telephone Number (TELN) Max. 16 digits
1 MEDIA
Media (1-15)
1=Voice 2=Data
3=FAX 4=Telex
5=Teletex 6=Image
7-15=Not used
2 CNTP
Connection Protocol (0-15)
0=ICS Protocol
1=X.20 2=X.21
3=V.24 200 Series
4=X.20 bis 5=X.21 bis
6-15=Not used
3 TCP
Transmission Control Protocol (0-255)
0=Free Wheeling
1=Synchronous Non Protocol
2=X.25 3=X.75
4=IBM2780 5=IBM3740
6=IBM3770 7=IBM3780
8=IBM BSC Polled (3270 Terminal)
9=IBM BSC Polling (3270 HOST)
10=IMB SDLC Polled (3270 Terminal)
11=IMB SDLC Polling (3270 HOST)
12=Teletex 13=Telex
14=FAX G3 MH
15=FAX G3 MR
16=FAX G4 MH
17=FAX G4 MR
18-255=Not used
4 FCY
Facility (0-3)
0=Bothway
1=Outgoing
2=Incoming
3=Not used
5 PRI
Priority (0/1)
0=Outgoing 1=Incoming
6 RST
Restriction (0/1)
0=Connection is restricted
1=Connection is not restricted
7 SRP
Send Receive Priority (0/1)
0=Data Receive Priority for Called Party
1=Data Send Priority for Called Party
8CI
CI Signal Control (0/1)(1 digit fix)
0=CI Signal Interval Control
1=CI Signal Continuous Control
To Next Page
