NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 384
Revision 3.0
ADA2
4. Data Sheet
CDN
TENANT NUMBER (TN)
STATION
NUMBER
FUNCTION (STN)
1
DTR (ER) CONTROL (DTR)
0= Check 1= No Check
2
AUTO ANSWER (AUTO)
0= Manual Answer
1= Auto Answer
3
MODEM No. FOR
ORIGINATING (MDM1)
0= No MODEM
1-8= MODEM Number
4
MODEM No.FOR
INCOMING (MDM2)
0= No MODEM
1-8= MODEM Number
5
BIT SPEED RATE(SPD)
0= 50 bps 1=75 bps
2= 110 bps 3= 150 bps
4= 200 bps 5= 300 bps
6= 600 bps 7= 1200 bps
8= 2400bps
9= 4800 bps
10= 9600 bps
11= 19.2 K bps
12= 48 K bps (SYNC)
13= 56 K bps (SYNC)
14= 64 K bps (SYNC)
15-31= Not used
6
PARITY ADDITION (PRTY)
0= No Parity 1= Parity
7
ASYNCHRONOUS(ASYC)
0= Asynchronous
1= Synchronous
8
HALF/FULL DUPLEX(HDX)
0= Full Duplex
1= Half Duplex
9
STOP BIT(STOP)
0= 1 bit
1= 2 bit
