ND-70348 (E) CHAPTER 4
Page 387
Revision 3.0
ADA2_T
4. Data Sheet
Note: The existing data can be readout by pressing “Get” button after UGN and TELN is entered.
CDN
User Group Number (UGN)
Telephone Number (TELN) Max. 16 digits
1 DTR
DTR (ER) Control (0/1)
0=Check 1=No Check
2 AUTO
Auto Answer (0/1)
0=Manual Answer
1=Auto Answer
3 MDM1
Outgoing MODEM Number (0-8)
0=No MODEM
1-8=MODEM Number
4 MDM2
Incoming MODEM Number (0-8)
0=No MODEM
1-8=MODEM Number
5 SPD
Bit Speed Rate (0-31)
0=50 bps. 1=75 bps.
2=110 bps. 3=150 bps.
4=200 bps. 5=300 bps.
6=600 bps. 7=1200 bps.
8=2400 bps. 9=4800 bps.
10=9600 bps. 11=19.2 Kbps.
12=48.0 Kbps. 13=56.0 Kbps.
14=64 Kbps. 15-31=Not used
6PRTY
Parity Addition (0/1)
0=No Parity 1=Parity
7 ASYC
Asynchronous (0/1)
0=Asynchronous 1=Synchronous
8 HDX
Half/Full Duplex (0/1)
0=Full Duplex 1=Half Duplex
9STOP
Stop Bit (0/1)
0=1 bit 1=2 bit
10 CODE
Application Code (0-15)
0=No Character
1=ASCII (7-bit) Even Parity
2=ASCII (7-bit) Odd Parity
3=ASCII (7-bit) Parity is “0”
4=ASCII (7-bit) Parity is “1”
5=JIS (7-bit) Even Parity
6=JIS (7-bit) Odd Parity
7=JIS (8-bit) 8=EBCDIC (8-bit)
9=IA #5 (7-bit) 10=ITA #2 (5-bit)
11=EBCD 12-15=Not used
To Next Page
