NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 418
Revision 3.0
ARTDN
LGRT
1-899
FUNCTION
REMARKS
32
ICRL Release timing for incoming trunk connections.
0= 288 msec. Note 1= 224 msec.
2= 288 msec. 3= 352 msec.
4= 416 msec. 5= 480 msec.
6= 544 msec. 7= 608 msec.
8= 672 msec. 9= 736 msec.
10= 800 msec. 11= 864 msec.
12= 928 msec. 13= 992 msec.
14= 1056 msec. 15= 1120 msec.
• Normally assign
data “0”.
• For ISDN, see Ta-
ble 4-23
(page
427)
(Example of
Route Class Set-
tings).
Note: 160 msec. in
case of Loop
Dialing
Trunk.
33
HD Trunk Hold Timing.
0= 10 sec. 1= 2 sec.
2= 4 sec. 3= 6 sec.
4= 8 sec. 5= 10 sec.
6= 12 sec. 7= 14 sec.
8= 16 sec. 9= 18 sec.
10= 20 sec. 11= 22 sec.
12= 24 sec. 13= 26 sec.
14= 28 sec. 15= 30 sec.
Normally assign data “0”.
34
GUARD Ground Timer
Outgoing inhibit timing after trunk release.
0= 3072 msec. 1= 512 msec.
2= 1024 msec. 3= 1536 msec.
4= 2048 msec. 5= 2560 msec.
6= 3072 msec. 7= 3584 msec.
8= 4096 msec. 9= 4608 msec.
10= 5120 msec. 11= 5632 msec.
12= 6144 msec. 13= 6656 msec.
14= 7168 msec. 15= 7680 msec.
• Normally assign
data “0”.
• For ISDN, see Ta-
ble 4-23
(page
427)
(Example of
Route Class Set-
tings).
35
WINK Width of a Wink Signal
0= 160 msec. 1= 64 msec.
2= 96 msec. 3= 128 msec.
4= 160 msec. 5= 192 msec.
6= 224 msec. 7= 265 msec.
8= 288 msec. 9= 320 msec.
10= 352 msec. 11= 384 msec.
12= 416 msec. 13= 448 msec.
14= 480 msec. 15= 512 msec.
Normally assign data “0”.
36 VAD 0000Always assign data “0”.
37 CLD 0000Always assign data “0”
