ND-70348 (E) CHAPTER 4
Page 504-1
Revision 5.0
ARTI
Note 1:
This data is valid for the software Release 11 or later.
Note 2:
Do not choose 1-14 unless very familiar with this configuration.
Assign the same NI2ID to PRI routes which has been contracted with a PSTN.
Note 3:
Recommended Configuration.
All routes in the same node are supposed to be connected to a single N-ISDN2.
CDN
ROUTE NUMBER
TRUNK DATA
58 MCTFAC
MCT (MCID) Service Send Message (for Aus-
tralia only)
0 = When using MCT (MCID) service, send IN-
FORMATION message
1 = When using MCT (MCID) service, send FA-
CILITY message
Note 1
59 RE
Recall Supplementary Service
0/1 = Out of service/In service
Note 1
60 PR
Path Replacement Additional Network Feature
0/1 = Out of service/In service
Note 1
61 COT
Continuity check for Signaling System No.7
0/1 = Out of service/In service
Note 1
62 SS7
Signaling System No.7
0/1 = CCITT No.7/SS7
Note 1
63 NI2ID
Identifier for National ISDN2 [0-15]
Note 1
0 = Out of service (the local carrier doesn’t sup-
port TBCT, or PBX doesn’t have it sub-
scribed with local carrier)
1-14 = In service when own and opposite side
NI-2 Trunks match this value. Otherwise
out of service.
Note 2
15 = In service when own and opposite side NI-
2 routes serve a same node (FPC) involved
in the same node. Otherwise out of service.
Note 3
64 CLRF
CCIS Link Reconnection for Netfusing
0/1 = Out of service/In service
Note 1
65 TRC
Transit Counter
0/1 = Out of service/In service
Note 1
66 OID
Object ID in Facility IE
0 = local 1 = global
Note 1
To Next Page
