NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 567
Revision 3.0
ADAI
b.) When “MODE=2 (Trunk)” is assigned
Note: See page 569 for other parameters.
MODE
1-3
ROUTE
NUMBER
(RT)
TRUNK
NUMER
(TK)
1-255
TEST LINE
CIRCUIT
(TLC)
0/1
USER SPEED
(USPEED)
0-31
HOT LINE
(HL)
0/1
INTERMEDIATE
RATE
(IRA)
0-3
ALARM
(ALM)
0/1
MODE
Assign "2".
1 = Station
2 = Trunk
3 = LENS
IRA
Assign Intermediate Rate, based
on the LLC information element
0 = Not assigned
1 = 8kbps
2 = 16kbps
3 = 32kbps
Assign the User Rate, based
on the LLC (Low Layer
Compatibility) information
element (TTC Q931).
Test Circuit Card
0/1 = Not exist/Exist
TLC
0 = -
1 = Alarm
ALM
Hot Line Recognition
0 = -
1 = Use Hot Line
HL
2
USPEED
Enter the External Route
Number only when MODE=2
is set.
RT
Enter the Trunk Number
only when MODE=2 is set.
TK
