NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 571
Revision 3.0
ADAI_T
4. Data Sheet
a.) When MODE = TELN is selected:
Note: The existing data can be readout by pressing “Get” button after UGN and TELN is entered. If the data
doesn’t exist, input the data and then press “Set” button.
CDN
MODE
TELN
User Group Number (UGN)
Telephone Number (TELN) Max. 16 digits
Fusion Point Code (FPC) 1-253
Tenant Number (TN)
Station Number (STN) Max. 6 digits
1 USPEED User Speed [0-31]
Assign the User Rate, based on the LLC (Low Layer
Compatibility) information element (TTC Q931) within
the range from 0-31
2 TLC Test circuit card Exist/Not exist [0/1]
0 = Non Exist
1 = Use Hot Line
3 HL Hot Line Recognized [0/1]
0 = -
1 = Use Hot Line
4 IRA Intermediate Rate, based on the LLC (Low Layer Com-
patibility) information element.
0 = Not Assigned
1 = 8 Kbps
2 = 16 Kbps
3 = 32 Kbps
5 ALM Alarm
0 = -
1 = Alarm
6 139MTC No Answer Individual Timer overriding SYS1,
INDEX139 of ASYD Miscellaneous Timer Class [0-15]
139MTC × 139TC
7 139TC No Answer Individual Timer overriding SYS1,
INDEX139 of ASYD Miscellaneous Timer Class [0-7]
139MTC × 139TC
8 140MTC No Answer Individual Timer overriding SYS1,
INDEX140 of ASYD Miscellaneous Timer Class [0-15]
140MTC × 140TC
9 140TC No Answer Individual Timer overriding SYS1,
INDEX140 of ASYD Miscellaneous Timer Class [0-7]
140MTC × 140TC
10 141MTC No Answer Individual Timer overriding SYS1,
INDEX141 of ASYD Miscellaneous Timer Class [0-15]
141MTC × 141TC
11 141TC No Answer Individual Timer overriding SYS1,
INDEX141 of ASYD Miscellaneous Timer Class [0-7]
141MTC × 141TC
12 247MTC No Answer Individual Timer overriding SYS1,
INDEX247 of ASYD Miscellaneous Timer Class [0-15]
247MTC × 247TC
13 247TC No Answer Individual Timer overriding SYS1,
INDEX247 of ASYD Miscellaneous Timer Class [0-7]
247MTC ×247TC
