ND-70348 (E) CHAPTER 4
Page 634
Revision 3.0
AFPC
3. Data Entry Instructions
Note 1: “USE_GATE” data is automatically set and this parameter won’t appear on the MAT display since
Release 8 software enhancement. This data assignment is required of Release 7 or earlier software only.
Note 2: It depends on the assignment on P_ROUTE parameter, whether the direct connection or FCH connec-
tion routing is selected.
In redundant configuration of internal LAN, #A/#B system changeover is to be activated in case all the
routes, both for direct connection and FCH connection, are unable to communicate.
According to the P_ROUTE assignment, the route is selected in the following order;
When “0=FCCH” is selected,
#A direct connection
→
FCH #A
→
#B direct connection
→
FCH #B
or
#B direct connection
→
FCH #B
→
#A direct connection
→
FCH #A
When “1=FGH” is selected,
FCH #A
→
#A direct connection
→
FCH #B
→
#B direct connection
or
FCH #B
→
#B direct connection
→
FCH #A
→
#A direct connection
1
23
456
78
10 10 10 10 10 10 10 10
11 11 11 11 11 11 11 11
CONNECTION ROUTE
(C_RT)
1-1023
FCCH NUMBER/FUSION
POINT CODE NUMBER
(FCHN/FPCN) 1-255/1-253
CNT
FUSION POINT
CODE (FPC)
1-253
FCCH USE OR
NOT USE (FCCH)
0/1
GATEWAY FUNCTION
USE (USE_GATE)
0/1
PRIORITY ROUTE
(P_ROUTE)
0/1
9
1
FPC
C_RT
FCCH
FCHN/FPCN
The Connection Route
(B-channel)
If "FCCH=0 (FCH card is not used.),
assign Fusion Point Code Number of the final
destination node.
If "FCCH=1 (FCH card is used.),
assign the FCCH number
FPC is the unique number allocated
to each node.
Assign FPC of the final destination node
in this parameter.
0=The FCH card is not used
1=The FCH card is used
0=Gateway Function is not used
1=Gateway Function is used
P_ROUTE
0=FCCH
1=FGH
USE_GATE
Note 1
Note 2
To Next Page
