ND-70348 (E) CHAPTER 4
Page 642-3
Revision 4.0
AVIPS
a.) Voice Data (for FCCS/CCIS/H.323)
JIT_ACT
0 = Conforms to switch setting on the IPTRK
1 = Static Jitter Buffer Action
2 = Dynamic Jitter Buffer Action
PAY_TYP
0 = Conforms to switch setting on the IPTRK
1 = Standard Setting (G.729a→G.723.1 (6.3K)→G.723.1 (5.3K)→G.711)
2 = Voice Quality Precedence Mode (G.711→G.729a→G.723.1 (6.3K)→G.723.1 (5.3K))
3 = Band Precedence Mode 1 (G.723.1 (5.3K)→G.723.1 (6.3K)→G.729a→G.711)
4 = Band Precedence Mode 2 (G.723.1 (6.3K)→G.723.1 (5.3K)→G.729a→G.711)
FAX_DET
0 = Conforms to switch setting on the IPTRK
1 = Voice/FAX Automatic Distinction
2 = Fixed to Voice Mode
3 = FAX Detection Available Timer after Starting Speech => 1 min
4 = FAX Detection Available Timer after Starting Speech => 2 min
5 = FAX Detection Available Timer after Starting Speech => 3 min
6 = FAX Detection Available Timer after Starting Speech => 4 min
7 = FAX Detection Available Timer after Starting Speech => 5 min
PAY_SIZ
0 = Conforms to switch
setting on the IPTRK
1 = 10ms
2 = 20ms
3 = 30ms
4 = 40ms
FAX_ECM
0 = Conforms to switch
setting on the IPTRK
1 = ECM ON
2 = ECM OFF
FAX_TYP
0 = T.30
1 = T.38 (UDP)
2 = T.38 (TCP)
RTCP_PTN
0 = Fixed rate
1 = random
RTCP_CYC
0 = 5sec
1-5 = Not used
6-120 = 6-120sec
FAX_RATE
0 = 14400bps
1 = 2400bps
2 = 4800bps
3 = 7200bps
4 = 9600bps
5 = 12000bps
TYPE OF JITTER
BUFFER ACTION
(JIT_ACT)
[0-2]
PAYLOAD TYPE
SELECTION
PATTERN
(PAY_TYP)
[0-4]
PAYLOAD SIZE
(PAY_SIZ)
[0-4]
FAX ERROR
DETECTION TIMER
(FAX_DET)
[0-7]
FAX ECM MODE
(FAX_ECM)
[0-2]
FAX MODE
CONTROL
PRECEDENCE
(FAX_TYPE)
[0-2]
FAX
TRANSMISSION
RATE
(FAX_RATE)
[0-5]
RTCP PATTERN
(RTCP_PTN)
[0/1]
RTCP CYCLE
(RTCP_CYC)
[0-120]
REMARKS
To Next Page
