ND-70348 (E) CHAPTER 4
Page 648-1
Revision 4.0
AIPDN
Note 1:
Available combination of the incoming/outgoing terminal is shown in the table below.
X: Available
Note 2:
“NODE” parameter is valid when CCIS/FCCS over IP or H.323 service is performed.
Note 3:
In case the ASIPN command is not assigned, or Telephone Numbers are not allocated, the IPG data is re-
garded as “0”.
Note 4:
When “IPG” is selected in IC/OG Terminal parameter, refer to the table below for the PAD value setting.
1 = 2dB 6 = 12dB
2 = 4dB 7 = 14dB
3 = 6dB 8 = 16dB
4 = 8dB 9-15 = 0dB
5 = 10dB
PAD Value and Data Assignment
–: No data assignment
×
: Data assignment
OG TERMINAL
IC
TERMINAL
LGRT SFC NODE IPG
LGRT
--XX
SFC
---X
NODE
XXXX
IPG
XXXX
IC PAD OG PAD IC PAD Value OG PAD Value
– X 0 [dB] the above value
X – the above value 0 [dB]
– – conforms to circuit card conforms to circuit card
X X the above value the above value
