ND-70348 (E) CHAPTER 4
Page 652-3-1
Revision 5.0
ASIPL
Note 1:
When Payload Type G723.1 (5.3k) and G723.1 (6.3k) is to be assigned on the same terminal, specify the
same value to the Payload Size of both type.
Note 2:
For Payload Type G.711 and G.729A , the value 10ms, 20ms, 30ms, or 40ms can be selected to the Payload
Size. For Payload Type G.723.1 (5.3k) and G.723.1 (6.3k), the value 30ms or 60ms can be selected.
0=Not used 1=10ms
2=20ms 3=30ms
4=40ms 5=Not used
6=60ms 7-15=Not used
The same Payload type cannot be
assigned on the same terminal.
0=Not used
1=G.711
2=G.729A
3=G.723.1 (5.3k)
4=G.723.1 (6.3k)
5-15=Not used
THE n-th PRIORITY
PAYLOAD TYPE
(PRIn PAYLOAD_TYPE)
n=1-4
THE n-th PRIORITY
PAYLOAD SIZE
(PRIn PAYLOAD_SIZE)
n=1-4
PRIn PAYLOAD_TYPE
PRIn PAYLOAD_SIZE
Note:
REMARKS
