NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 739
Revision 3.0
AHSY
INDEX
(0 – 2047)
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
CONTENTS
DATA
0/1
BIT
400
“Hour” data is assigned using a decimal number (Mili-
tary Time).
Example: 2:00 a.m. – This data is entered as 02.
Example: 2:30 p.m. – This data is entered as 14.
The time at which
the printer periodi-
cally prints out the
setting status of
such Service Fea-
tures as Automatic
Wake-Up, Group
Announcement etc.
401
“Minute” data is assigned using a decimal number (Mil-
itary Time).
Example: 2:00 a.m. – This data is entered as 00.
Example: 2:30 p.m. – This data is entered as 30.
402
0
b
0
Not used
b
1
Wake-Up Result (Answer) Printout
0/1 = Out/In Service
0
b
2
Not used
0
b
3
0
b
4
0
b
5
0
b
6
0
b
7
