ND-70348 (E) CHAPTER 4
Page 780
Revision 3.0
ASPS
Assign a dummy route number.
RT
Second dial tone sending (which is sent when a station has dialed
the digits specified in NND of the AANP/AGNP command)
0=Second DT is not send
1=Second DT is sent
2nd DT
Authorization code after dialing
ACC (LCR)+Destination number
0=Out of Service
1=In Service
AH
ISDN-Sub Address Dialing
0=Out of Service
1=In Service
SUB
ROUTE NUMBER
(RT)
SECOND DIAL TONE
(2nd DT) 0/1
AUTHORIZATION CODE
(AH) 0/1
SUB ADDRESS DIALING
(SUB) 0/1
When SRV=LCR (Least cost routing) is assigned;
When SRV=LCRS (Register sender LCR) is assigned;
Assign the skip digits to terminate the call.
Assign the announce equipment number.
EQP3 and 5-14 can be used for SRV=ANNC (Single announcement).
SKIP DIGITS
(SKIP) 0-5
When SRV=UNIF (Office termination) is assigned;
When SRV=ANNC (Announcement service-Single announcement) is assigned;
SKIP
ANNOUNCEMENT EQUIPMENT NUMBER
(EQP) 0-127
EQP
Note: This data is available for ACIS only. For CCIS, use the AUNE command.
To Next Page
