3. Data Entry Instructions
1 : DP (10pps) 2 : PB
3 : DP/PB 4 : DP (20pps)
5-8 : Not Used 9 : House Phone
10-11 : Not Used 12 : D
term
13 : Data Terminal via D
term
14 : Hot Line 15 : CAS Line
16 : Data Terminal via Data Module
17 : Not Used
18 : Virtual Line Appearance (for D
term
Multi-Line)
19-22 : Not Used 23 : ISDN Terminal
24-25 : Not Used 26 : Not Used
27 : Eight Conference Equipment
28-31 : Not Used
TEC
LENS
Enter the LENS
XX X XX X
Level No. (0-7)
Group No. (00-31)
Unit No. (0-3)
Module Group No. (00-31)
G
0 : Ground
1 : Underground
TENANT
NUMBER
(TN)
STATION
NUMBER
(STN)
Max.6 digits
TELEPHONE
EQUIPMENT
CLASS
(TEC)
1-31
ROUTE
RESTRICTION
CLASS
(RSC)
0-15
SERVICE
FEATURE
CLASS
(SFC)
0-15
ROOM
CLASS
0-15
ANNEX
(ANX)
0-3
GROUND/
UNDERGROUND
(G)
0/1
FLOOR
(FLR)
1-127
LINE EQUIPMENT
NUMBER
(LENS)
MG U G LV
ANNEX
0 : Main Building
1 : Annex 1
2 : Annex 2
3 : Annex 3
RSC
Enter the RSC defined by the ARSC command. Since RSC = 0 is
preserved for ATTCON, a station can be used the RSC range from 1 to 15.
SFC
Enter the SFC defined by the ASFC command. Since SFC = 0 is
preserved for ATTCON, a station can be used the SFC range from 1 to 15.
0 : General Administration (Ordinary Telephone, D
term
)
1 :
2 :
3 :
4 :
5 :
6 : Guest Service Telephone (D
term
and External Equipment)
7-15 : Not Used
Room Class
STN
Enter the station number with regard to the followings;
• The number of station number (STN) digits is designated
by the ASYD command, SYS1, INDEX 16.
Not Used
