ND-70348 (E) CHAPTER 4
Page 793
Revision 3.0
AACL
3. Data Entry Instructions
TEC
RSC
ANNEX
G
NOTE
STN
SFC
TENANT
NUMBER
(TN)
STATION
NUMBER
(STN)
Max. 6 digits
TELEPHONE
EQUIPMENT
CLASS
(TEC)
1-31
ROUTE
RESTRICTION
CLASS
(RSC)
0-15
SERVICE
FEATURE
CLASS
(SFC)
0-15
ROOM
CLASS
0-15
ANNEX
(ANX)
0-3
GROUND/
UNDERGROUND
(G)
0/1
FLOOR
(FLR)
1-127
1
12 1 1
1 : DP (10pps) 2 : PB 3 : DP/PB 4 : DP (20pps)
5-8 : Not Used 9 : House Phone 10-11 : Not Used 12 : D
term
13 : Data Terminal via D
term
14 : Hot Line 15 : CAS Line
16 : Data Terminal via Data Module 17 : Not Used
18 : Virtual Line Appearance (for D
term
Multi-Line)
19-22 : Not Used 23 : ISDN Terminal 24-25 : Not Used 26 : Not Used
27 : Eight Conference Equipment 28-31 : Not Used
Enter the RSC defined by the ARSC/ASCR/ADNR command. Since RSC = 0 is
preserved for ATTCON, a station can be used the RSC range from 1 to 15.
0 : Main Building
1 : Annex 1
2 : Annex 2
3 : Annex 3
0 : Ground
1 : Underground
Enter the station number with regard to the followings;
• The number of station number (STN) digits is designated
by the ASYD command, SYS1, INDEX 16.
Enter the SFC defined by the ASFC command. Since SFC = 0 is
preserved for ATTCON, a station can be used the SFC range from 1 to 15.
When you have changed the station class, update
the data sheet for the AAST command.
0 : General Administration (Ordinary Telephone, D
term
)
6 : Guest Service Telephone (D
term
and External Equipment)
15 : Guest Service Telephone
ROOM CLASS
1-5 : Not used
7-14 : Not Used
To Next Page
